AONano Compact (3D)

The new Compact 3D air-cooled model is designed with integrated structure, featuring small size, light weight and complete functions, which can save installation space, reduce integration cost and simplify installation and disassembly for customers. With the industry’s excellent thermal management system and heat dissipation structure, it can ensure the stable operation of the machine in 15-35°C environment.

All-in-one format: the optical cavity and electrical controller are integrated into a single box.

Power monitoring: the laser output power is monitored and consequently the real-time power reading is available in the laser GUI and RS232-command.

Compact (3D) UV 355nm laser is perfect choice for 3D printing machine, power 3W, repetition frequency 30-150KHz, with a short pulse width (<35ns@100k), superior beam quality (M2<1.2) and perfect beam roundness (>90%), making it the perfect choice for 3D printing and so on.

AONano Compact (3D)
Specification 3W-50K-3D
Wavelength (nm) 355
Average Power (Watts) >3W@100KHz
Energy (µJ) >30
Specified Repetition Rate(kHz) 100
Repetition Rate (kHz) 30 ~ 150
Pulse Width (ns)  <30
Beam Quality (M²) <1.2
Beam Roundness (%) >90
Beam Diameter (mm) ~0.45
Beam Divergence (mRad) <1.5
Point Stability (µRad/°C) <20
Polarization Ratio 100:1 Linear, Horizontal
Pulse-to-Pulse Stability (% RMS) <3
Average Power Stability(% over 12 hours) <3
Cold Start Warm-Up <40
Standby Warm-Up <10
Operational Temperature Range (°C) 15-35°C
Operation Humidity Range (%) 20 to 80, non-condensing
Storage Temperature Range (°C) -20 to 50
Storage Humidity Range 20 to 80, non-condensing
Input Voltage (VDC)/Rated Power (W) 12/350
Power Consumption(W) <110
Communication RS232
Cooling Air
Weight (kg) 5.48
