AONano XP series 355nm Laser

Features & Benefits:

The all-in-one design makes the laser more compact and reduces the total weight. It saves space for installation on the customer side, lowers the integration cost and simplifies the installation process. The water-cooled design allows the laser to work reliably in various harsh and extreme environments and makes the laser to be the ideal candidate for the 7×24 non-stop production needs.

The output power of 5W, and up to 30W are available for selection. With the pulse width of ~ 2 ns, high repetition rate up to 2 MHz, it is the perfect candidate for various application areas, including on-fly marking, ink removal, and so on.



AONano XP 355nm

AONano XP 355
Specification 15W-1000K 30W-2000K
Wavelength (nm) 355
Avg. Power >15W @ 1000KHz >30W @ 2000KHz
Pulse Energy (µJ) >15 >15
Pulse Width (ns) <3
Operating Rep. Rate Range (kHz) 100~1000 100~2000
Beam Quality (M²) <1.2
Beam Roundness (%) >90
Beam Diameter (mm) ~2.5
Beam Divergence (mRad) <1
Point Stability (µRad/°C) <20
Polarization Ratio 100:1 Linear, Horizontal
Pulse-to-Pulse Stability (% RMS) <3
Average Power Stability (% over 12 hours) <3
Cold Start Warm-Up (mins.) <30
Standby Warm-Up (mins.) <10
Operational Temperature Range (°C) 15 to 35
Operation Humidity Range (%) 20 to 80, non-condensing
Storage Temperature Range (°C) -20 to 50
Storage Humidity Range (%) 20 to 80, non-condensing
Input Voltage (VDC)/Rated Power(W) 24/450
Communication RS232
Cooling Water
Laser head (kg) 32
